200 AH MULTIPLE BATTERY ISOLATOR

5.00 out of 5 based on 2 rating write a preview

73,07$

New!

In stock

Description

Metal switch,Not a plastic switch.
SPECIFICATIONS:
Input voltage: 9-36V
Continuous pass-through current: 150A
Peak current: 200A
Connect voltage (Delay 2 min): 13/26V
Connect voltage (Delay 1 min): 13.8/27.6V
Disconnect voltage (Delay 5 min): 12.8/25.6V
Disconnect voltage (Delay 20 sec): 11.8/23.6V
Press 3 sec to close the remote switch: Disconnection in 60 sec
OVP voltage (No Delay): 16/32V
Work current consumption: <500mA
Idle current consumption: <15mA
Work temp: -20 ~ 85°C
Weight: 0.3 kg
Dimensions: 55x76x85 mm
Battery Capacity (AH): <600 AH
Included in package: 1x Battery Isolator

Additional information

Brand Name

TYTXRV

Item Height

8.5cm

Item Length

5.5cm

Item Weight

0.3kg

Item Width

7.6cm

Model Name

200A
